Trommel Type Sand Washing Machine

Trommel type sand washer is designed to classifying, washing and removing impurities from sand, gravel, mineral, frac sand, coal, metal mine tailings, ceramic, piling mud, river dredging and construction waste, thereby improving the products quality.

Introduction to Trommel Type Sand Washing Machine

According to the needs of customers, the matetials should be grading and screening before washing and dewatering. Our technical department has designed this new type of screening and washing machine. LZZG called it compact sand washer with trommel screen.
Application: mining, aggregate processing, piling mud, river dredging, city construction waste incineration, ceramic raw material, silica sand production and various kinds of metal ores, tailings disposal and other industries.

Trommel Type Sand Washing Machine

Working principle

Screening: The Trommel Screen is also called rotary screen or drum screen, which screening the material into different size.
Washing: The bucket is driven by the motor through the reducer and rotates in circle. There are many sand storage web grooves and bucket screen for sand storage and primary dewatering. When the bucket moves, sand can be put out by sand storage web groove after being cleaned in the cleaning tank and primary dewatered on the bucket screen.
Recycling: Flowing slurry water is extracted by slurry pump, fine sand is collected by the centrifugal force of the cyclone, then fed to the polyurathane screen from the apex spray. The 0.16-3mm fine sand and water are efficiently separated through the vibration screen.
Dewatering: coarse sand (3-10mm) and fine sand (0.16-3mm) are fed onto polyurathane vibrating screen for dewatering.

Features

1.Flexibility, high production rates, serviceability and low maintenance.
2.Compact structure, saving land area. 3.High efficiency and cost saving.

Specifications

Model Feed Size (mm) Capacity (t/h) Roller Size (mm) Impeller Size (mm) Hydrocyclone (mm) Screen Panel (mm) Power (kw) Weight (kg) Overall Size (mm)
SX10-18-55-1224 ≤10 20-40 φ1000 1800*800 250*2 1200*2400 32.4 7200 6800*4980*2950
SX10-26-65-1530 ≤10 30-60 φ1000 2600*1200 300*2 1500*3000 43 9600 7450*5600*3050
SX12-30-75-1842 ≤10 40-80 φ1200 3000*1600 350*2 1800*4200 59 14600 4800*5800*3300
SX12-30-75-1842J ≤10 60-100 φ1200 3000*1600 350*2 1800*4200 63 16850 4800*5800*3300
SX12-30-120-2442J ≤10 80-120 φ1200 3000*1600 300*2 2400*4200 93 18600 4800*6200*3300
SX15-36-120-2442J ≤10 100-150 φ1500 3600*2000 300*4 2400*4200 100.5 22600 5800*6200*4000
SX18-36-140-3048J ≤10 120-200 φ1800 3600*2400 350*4 3000*4800 130 25720 6700*7200*4600
SX24-42-180-3660J ≤10 160-250 φ2400 4200*3000 300*6 3600*6000 171 34300 6700*7200*4600
